[ UNMANNED AIRCRAFT / 02 ]
KÖPARI
FAMILY.
RUGGED. FAST-DEPLOYMENT. MULTI-MISSION.
A modular, carbon-fiber tactical UAS family proven across tropical rainforests, savannahs, and deserts.
[ PLATFORM ]
KÖPARI
NASR (نصر).
Köpari (Hawk in Yanomami language) is an aircraft designed for rapid-deployment in rugged operational conditions, manufactured following strict Military standards with carbon fiber and aramide.
Köpari is slim, light, and aerodynamically efficient. Manufactured in Hexcel carbon fiber and Kevlar, and powered by a high-end fuel-injected engine.
This airframe offers versatile payload bay space capacity and high payload/airframe weight ratio. The airframe architecture makes this aircraft easy and fast to manufacture, reducing costs of acquisition and maintenance.
Rugged and reliable, proven in the harshest operational environments. Be it in tropical rainforests, savannahs or deserts, you can rely on Aerofoundry’s Köpari to get the job done.
This is a very light, easy-to-assemble UAS designed upon the experience acquired from our Yaró 450 and 400 models, and is our airframe optimization response to payload miniaturization and increased operational requirements in this segment.
This highly dependable aircraft is designed for ruggedness, easy assembly, servicing and maintenance, and can be deployed by a team of two servicemen in 30 minutes (depending on payload configuration). The entire turnaround process, from recovery to re-launch, takes less than 15 minutes.
A body length payload compartment with three covers provides easy access to the different payload components, distributed electric sockets, and wide pipes for extra wiring and fiber optics.
[ 01 / VARIANTS ]
TACTICAL
CONFIGURATIONS.
- Köpari 360 for Border Patrol: Light version fitted with an EO/MWIR gyro gimbal integrated with a long-range laser rangefinder (LRF) and Laser Target Pointer (LP) with a range of <5km. Ensures an endurance of 8 hours, with a flight range of 80km (datalink for 100km).
- Köpari 500 for Maritime Patrol: Suited with an EO/MWIR gyro gimbal integrated with a long-range laser rangefinder (LRF) and Laser Target Pointer (LP) with a range of <8km. Ensures an endurance of <14 hours, with a datalink safe range of 120km (capable of 150km range).
- Köpari 400 for Active Battlefield ISR: Configured with underbelly ballistic protection for payload, electronics, engine, and fuel tank. Carries an EO/LWIR gyro gimbal integrated with long-range LRF and LP (<5km range). Ensures an endurance of <14 hours, with a datalink safe range of 80km (capable of 100km range).
[ 02 / HIGHLIGHTS ]
OPERATIONAL
HIGHLIGHTS.
- Rapid Turnaround: Deployable in 30 minutes by a two-person team; turn-around time from recovery to re-launch under 15 minutes.
- Ballistic Shielding: Integrated underbelly composite armor protecting critical avionics, fuel cell, and optical gimbal systems.
- Full Body-Length Modular Bay: Three independent access hatches with distributed power distribution and dedicated optical fiber channels.
- Harsh Environment Proven: Tropicalized and desert-hardened architecture operating smoothly in heavy humidity and severe dust conditions.
- Multi-Payload Flexibility: Supports EO/IR gimbals, LiDAR, hyperspectral imaging, and tactical communications relays.
[ 03 / DATA ]
KÖPARI 360
SPECIFICATIONS.
The Köpari 360 Border Patrol configuration is engineered for high agility, low acoustic footprint, and reliable day/night border reconnaissance.
- MTOW
- 25 kg
- Cruise speed (V cruise)
- 30 m/s
- Maximum speed (V max)
- 36 m/s
- Endurance
- < 8 hrs
- Range
- > 900 km
- Payload capacity
- < 5 kg
[ 04 / DATA ]
KÖPARI 500 & 400
SPECIFICATIONS.
Köpari 500 Maritime Patrol Data:
- MTOW
- 70 kg
- Cruise speed (V cruise)
- 33 m/s
- Maximum speed (V max)
- 37 m/s
- Endurance
- < 14 hrs
- Range
- > 1,400 km
- Payload capacity
- 5–8 kg
Köpari 400 Battlefield ISR Data:
- MTOW
- 48 kg
- Cruise speed (V cruise)
- 28–33 m/s
- Maximum speed (V max)
- 36–39 m/s
- Endurance
- 8–14 hrs
- Range
- > 1,100 km
- Payload capacity
- 7 kg
[ KÖPARI / CONTACT ]
CONFIGURE
YOUR
MISSION.
Talk to Aerofoundry about a Köpari 360, 400, or 500 configuration tailored to your operational profile and payload payload requirements.
